grounding rods
GROUNDING RODS
own manufacture since 1923
We are a pioneer manufacturer in the design and manufacture of high-thickness copper rods with great mechanical rigidity and maximum corrosion resistance, connection accessories and branches in Europe. Our stakes comply with the UNE 202006 (2019) standard “Grounding electrodes for low voltage installations. Cylindrical steel-copper attachable rods and accessories ”, UL 467 (2013)“ Safety standard. Grounding and bonding equipment "EC 62561-2 (2018)" Components of the lightning protection system (LPSC) - Part 2: Requirements for conductors and ground electrodes "and UNE 21056 (1981)" Grounding electrodes . Cylindrical steel-copper attachable rods "
Electroniquel rohs compliant
reference E 1014 15-25 microns cooper bonded
1000x13,70 | Ø 13,70 | 1,16 Kg
reference E 1514 15-25 microns cooper bonded
1500X13,70 | Ø 13,70 | 1,75 Kg
reference E 2014 15-25 microns cooper bonded
2000X13,70 | Ø 13,70 | 2,45 Kg
reference E 1014 RR 15-25 microns cooper bonded
1000x5/8 | Ø 5/8" | 1,16 Kg
reference E 1514 RR 15-25 microns cooper bonded
1500X5/8 | Ø 5/8" | 1,75 Kg
reference E 2014 RR 15-25 microns cooper bonded
2000X5/8 | Ø 5/8" | 2,45 Kg
Electroniquel rohs compliant
UNE 202006
reference E 1514 100 microns cooper bonded
1000x14,2 | Ø 14,2 | 1,85 Kg
reference EC 2014 100 microns cooper bonded
2000X14,2 | Ø 14,2 | 2,47 Kg
reference EC 1514 RR 100 microns cooper bonded
1500XM16 | Ø M16 | 1,85 Kg
reference EC 2014 RR 100 microns cooper bonded
2000xM16 | Ø M16 | 2,47 Kg
reference EC 1518 100 microns cooper bonded
1500X18 | Ø 18 | 2,97 Kg
reference EC 2018 100 microns cooper bonded
2000X18 | Ø 18 | 3,95 Kg
reference EC 1518 RR 100 microns cooper bonded
1500xM20 | Ø M20 | 2,97 Kg
reference EC 2018 RR 100 microns cooper bonded
2000XM20 | Ø M20 | 3,95 Kg
Electroniquel rohs compliant
reference E 1014 RR 150 microns cooper bonded
2000x14,6 | Ø 14,6 | 2,65 Kg
reference EL 2014 RR 150 microns cooper bonded
2000X5/8 | Ø 5/8 | 2,55 Kg
reference EL 2018 150 microns cooper bonded
2000X18 | Ø 18 | 4 Kg
reference EL 2018 RR 150 microns cooper bonded
2000xM20 | Ø M20 | 4 Kg
reference EL 1519 150 microns cooper bonded
1500X18,9 | Ø 18,9 | 3,3 Kg
reference EL 1519 RR 150 microns cooper bonded
13/16 | Ø 13/16 | 3,3 Kg
Electroniquel rohs compliant
UL SPEC 467 EN 62305-3 EN 50164-2 BS 6651
reference EX 1058 254 microns cooper bonded
1000X16 | Ø 14,2 | 1,25 Kg
reference EX 1258 254 microns cooper bonded
1200X16 | Ø 14,2 | 1,5 Kg
reference EX 1558 254 microns cooper bonded
1500 | Ø 14,2 | 1,90 Kg
reference EX 2058 250 microns cooper bonded
2000X16 | Ø 14,2 | 2,58 Kg
reference E 1014 RR 250 microns cooper bonded
2400X16 | Ø 14,2 | 3 Kg
reference EX 1058 250 microns cooper bonded
1000| Ø 5/8 | 1,25 Kg
reference EX 1258 RR 250 microns cooper bonded
1200X5/8 | Ø 5/8 | 1,5 Kg
reference EX 1558 RR 250 microns cooper bonded
1500X5/8 | Ø 5/8 | 1,90 Kg
reference EX 2058 RR 250 microns cooper bonded
2000x5/8 | Ø 5/8 | 2,5 Kg
reference EX 2458 250 microns cooper bonded
2400X5/8 | Ø 5/8 | 3 Kg
reference EX 1034 250 microns cooper bonded
1000X19 | Ø 17,3 | 1,8 Kg
reference EX 1234 250 microns cooper bonded
1200x19 | Ø 17,3 | 2,3 Kg
reference EX 1534 250 microns cooper bonded
1500X19 | Ø 17,3 | 2,66 Kg
reference EX 2034 250 microns cooper bonded
2000X19 | Ø 17,3 | 3,57 Kg
reference EX 2434 250 microns cooper bonded
2400x19 | Ø 17,3 | 4,32 Kg
reference EX 1034 RR 250 microns cooper bonded
1000X3/4 | Ø 3/4 | 1,8 Kg
reference EX 1234 250 microns cooper bonded
1200X3/4 | Ø 3/4 | 2,3 Kg
reference EX 1534 RR 250 microns cooper bonded
1500x3/4 | Ø 3/4 | 2,7 Kg
reference EX 2034 RR 250 microns cooper bonded
2000X3/4 | Ø 3/4 | 3,5 Kg
REFERENCIA EX 2434 RR 250 MICRAS DE COBRE
2400X3/4 | Ø 3/4 | 4,32 Kg
Grounding rods EN - 300 Microns copper bonded
UL SPEC 467 EN 62305-3 EN 50164-2 BS 6651
reference EN 1515 300 microns cooper bonded
1500X14,6 | Ø 14,6 | 1,92 Kg
reference EN 2015 300 microns cooper bonded
2000X14,6 | Ø 14,6 | 2,45 Kg
reference EN 1515 RR 300 microns cooper bonded
1500XM16 | Ø M16 | 1,92 Kg
reference EN 2015 RR 300 microns cooper bonded
2000XM16 | Ø M16 | 2,45 Kg
reference EN 1518 300 microns cooper bonded
1500X18,3 | Ø 18,3 | 3,20 Kg
reference EN 2018 300 microns cooper bonded
2000X18,3 | Ø 18,3 | 4,21 Kg
reference EN 1518 RR 300 microns cooper bonded
1500XM20 | Ø M20 | 3,12 Kg
reference EN 2018 RR 300 microns cooper bonded
2000XM20 | Ø M20 | 4,21 Kg
reference EN 2020 300 microns cooper bonded
2000X20,3 | Ø 20,3 | 5,05 Kg
reference EN 2020 RR 300 MICRAS DE COBRE
2000XM22 | Ø M22 | 5,05 Kg
Grounding rods EN - 350 Microns copper bonded self extensible
REFERENCE 0934 AA 350 MICRONS COPPER BONDED
975X3/4 | Ø 17,3 | 1,85 Kg
REFERENCE 1034 AA 350 MICRONS COPPER BONDED
1000X3/4 | Ø 17,3 | 1,90 Kg
REFERENCE 1534 AA 350 MICRONS COPPER BONDED
1500X3/4 | Ø 17,3 | 2,85 Kg
REFERENCE 2034 AA 350 MICRONS COPPER BONDED
2000X3/4 | Ø 17,3 | 3,80 Kg
Grounding rods EFX - 250 Microns copper bonded self extensible
REFERENCE EFX 1058 250 MICRONS COPPER BONDED
1000X14,2 | Ø 14,2 | 1,25 Kg
REFERENCE EFX 1558 250 MICRONS COPPER BONDED
1500X3/4 | Ø 14,2 | 1,90 Kg
REFERENCE EFX 2058 250 MICRONS COPPER BONDED
2000X14,2 | Ø 14,2 | 2,58 Kg
REFERENCE 1034 AA 250 MICRONS COPPER BONDED
1000X17,3 | Ø 17,3 | 1,90 Kg
REFERENCE 1534 AA 250 MICRONS COPPER BONDED
1500X17,3 | Ø 17,3 | 2,85 Kg
REFERENCE 2034 AA 250 MICRONS COPPER BONDED
2000X17,3 | Ø 17,3 | 3,80 Kg
REFERENCE EXFFDM 1034 250 MICRONS COPPER BONDED
1000X17,3 | Ø 17,3 | 1,77 Kg
Grounding rods - EFI - STAINLESS STEEL SELF EXTENSIBLES EARTH RODS
REFERENCE EFI 1016 AA STAINLESS STEEL
1000X16 | Ø 16 | 1,5 Kg
REFERENCE EFI 1516 AA STAINLESS STEEL
1500X17,3 | Ø 16 | 2,25 Kg
REFERENCE EFI 2016 AA STAINLESS STEEL
2000X16 | Ø 16 | 3 Kg
Grounding rods - ES - STAINLESS STEEL
REFERENCE ES 1516 STAINLESS STEEL
1000X16 | Ø 16 | 2,25 Kg
REFERENCE ES 2016 STAINLESS STEEL
1500X17,3 | Ø 16 | 3 Kg
ZINC ANODES
REFERENCE EZ 1030 CATHODIC PROTECTION
1000X35X35 | Ø 1000X35X35 | 12,81 Kg
REFERENCE EZ 1530 CATHODIC PROTECTION
1500X60X60 | Ø 1500X60X60 | 13,50 Kg
REFERENCE EZSAC 1060 BACKFILL BAG AND 3MTS CABLE
1000X60X60 | Ø 1000X60X60 | 15 Kg
REFERENCE EZSAC 1560 BACKFILL BAG AND 3MTS CABLE
1500X60X60 | Ø 1500X60X60 | 29,29 Kg
THREADED COUPLES
REFERENCE MA14 THREADED FOR A EARTH RODS
13,70 - 14,2 | Ø 5/8" | 0,110 Kg
REFERENCE MA15 THREADED FOR A EARTH RODS
14,2 - 14,6 | Ø m16 | 0,100 Kg
REFERENCE MA15 CUAL THREADED FOR A EARTH RODS
14,2 - 14,6 | Ø M16 | 0,100 Kg
REFERENCE MA16 THREADED FOR A EARTH RODS
16,2 | Ø M 18 | 0,120 Kg
REFERENCE MA17 THREADED FOR A EARTH RODS
17,2 | Ø 3/4 | 0,130 Kg
REFERENCE MA18 THREADED FOR A EARTH RODS
18,3 | Ø M20 | 0,180 Kg
REFERENCE MA 19 10 THREADED FOR A EARTH RODS
19,1 | Ø 13/16 | 0,169 Kg
REFERENCE MA 19 THREADED FOR A EARTH RODS
19,1 | Ø A PRESION | 0,169 Kg
REFERENCE MA 21 THREADED FOR A EARTH RODS
20,3 | Ø M 22 | 0,147 Kg
REFERENCE MAM 10 THREADED FOR A EARTH RODS
17,3 [EXFFDM] | Ø M 10 | 0,027 Kg
BICROMATED STEEL
REFERENCE TS 14 BICHROMATED STEEL
Ø M 5/8 | 0,084 Kg
REFERENCE TS 15 BICHROMATED STEEL
Ø M 16 | 0,088 Kg
REFERENCE TS 16 BICHROMATED STEEL
Ø M 18 | 1,130 Kg
REFERENCE TS 17 BICHROMATED STEEL
Ø 3/4 | 0,142 Kg
REFERENCE TS 18 BICHROMATED STEEL
Ø M 20 | 0,159 Kg
REFERENCE TS 19 BICHROMATED STEEL
Ø 13/16 | 0,185 Kg
REFERENCE TS 21 BICHROMATED STEEL
M 22 | 0,235 Kg
REFERENCE CDS 20 BICHROMATED STEEL
Ø M 10 | 0,050 Kg
TEMPERED STEEL
REFERENCE SPK20 [EXFFDM] TEMPERED STEEL
M 10 | 0,050 Kg
REFERENCE DT 58 TEMPERED STEEL
5/8 | 0,156 Kg
DRIVING HEAD
REFERENCE S-15 TEMPERED STEEL
14,6 MM | 0,23 Kg
REFERENCE S-18 TEMPERED STEEL
18,3 MM | 0,24 Kg
REFERENCE S-21 TEMPERED STEEL
20,3 MM | 0,29 Kg
EARTHING PLATES
REFERENCE PT100100 COPPER PLATE
cobre | 500x500x2 | 4,5 Kg
REFERENCE PT5050 COPPER PLATE
cobre | 1000x1000x2 | 18 Kg
REFERENCE PTRO 100100 COPPER PLATE
cobre | 500x500x2 | 4,5 Kg
ENHACING MATERIAL
REFERENCE GEM ENHACING
Additives | Bag | 11,5 kg
